Category:

KEY SPECIFICATIONS

Specifications may vary by region. Please confirm with our sales team.

Unlock Methods
Face Recognition / Palm Vein / Fingerprint / Password / IC Card / Mechanical Key / App
Working Temperature
-20°C to 60°C
Power Supply
7.4V Lithium Battery
Battery Life
More than 1 year under typical standby conditions
Matched App
Tuya Smart
Face Capacity
100
Supported Language
Chinese / English / Multiple Languages
Total Password / Card Capacity
100

FEATURE DETAILS

Explore the key access and security functions of this model.

01Face RecognitionContactless access

Supports face recognition for door unlocking.

02Palm Vein RecognitionBiometric access

Supports palm-vein authentication as an available unlocking method.

03Fingerprint UnlockingFingerprint access

Supports fingerprint unlocking.

04Password UnlockingPIN-based access

Supports the listed password-based access method.

05Card AccessCard access

Supports card-based unlocking.

06Mechanical KeyPhysical key access

Mechanical key access is listed for this model.

07Anti-pry AlarmTamper alert

Includes an anti-pry alarm.

08Low Battery AlarmPower warning

Includes a low-battery alarm.

09Emergency ChargingEmergency power

Includes the listed emergency power connection.

10App ControlApp connection

App-based access is listed for this model. Matched app: Tuya Smart.

11Video IntercomVideo communication

Video intercom is listed as a function for this model.

12BluetoothConnected access

Bluetooth is listed for this model.

TECHNICAL SPECIFICATIONS

Technical parameters for this model.

Rated Voltage
7.4V
Low Voltage Alarm
7.0V ±0.1V
Standby Current
<100 μA
Password Length
6–10 digits
Working Current
<4A
Product videos

PRODUCT VIDEOS

Video count: 5

PRODUCT DOCUMENTS

Download product manuals, datasheets, installation guides and other available documents.
